تصميم PCB Stackup: دليل شامل من الأساسيات إلى تحسين الإشارة عالية السرعة



In modern electronic design, ثنائي الفينيل متعدد الكلور (لوحة الدوائر المطبوعة) stackup design is one of the key factors determining circuit performance, مصداقية, and cost. Especially when the number of layers exceeds four, stackup design not only affects signal integrity, electromagnetic compatibility (إي إم سي), and thermal management but also directly impacts manufacturing costs and process complexity. This article will start with fundamental concepts, delve into the core principles of لوحة الدوائر المطبوعة stackup design, material selection, and high-speed signal optimization strategies, helping engineers make more informed decisions during the design process.

Fundamentals of PCB Stackup Design

What is PCB Stackup?

PCB stackup refers to the process of stacking multiple layers of copper-clad cores (Core), prepreg (Prepreg, abbreviated as PP), and copper foil in a specific sequence, which are then laminated to form an integrated multilayer circuit board بناء. The core of stackup design lies in the rational allocation of signal layers, power layers, and ground layers to meet electrical performance, mechanical strength, and cost control requirements.

For single or double-layer boards, stackup design is relatively simple, typically requiring only the selection of appropriate copper-clad board thickness and copper weight. لكن, when designing multilayer boards with four or more layers, stackup design becomes complex and critical. على سبيل المثال, the stackup design of a 16-layer board must consider signal integrity, impedance control, EMC shielding, thermal management, وعوامل أخرى.

Key Materials in Stackup Design

• Copper-Clad Core (Core): Composed of insulating substrate (such as epoxy resin, الألياف الزجاجية) and copper foil, providing mechanical support and electrical insulation.
• Prepreg (Prepreg): Made of fiberglass cloth impregnated with epoxy resin, used for interlayer bonding and insulation.
• احباط النحاس: Used to form conductive traces, with common thicknesses of 0.5oz (18μm), 1أوقية (35μm), and 2oz (70μm).

Core Principles of PCB Stackup Design

Layer Allocation and Signal Integrity

When designing multilayer PCBs, the number of layers must first be determined based on circuit scale and EMC requirements. Typically, signal layers, power layers, and ground layers should be alternately distributed to reduce signal crosstalk and electromagnetic interference. على سبيل المثال, for high-speed signals, أ “GND/Signal/GND” stackup combination is recommended to minimize crosstalk coupling.

• Stripline: Suitable for critical high-speed signals, where the signal line is sandwiched between two ground planes, providing excellent shielding.
• Microstrip: Suitable for non-critical high-speed signals, where the signal line is on the outer layer, offering flexible routing but poorer shielding.

Impedance Control

Impedance control is one of the core aspects of high-speed PCB design. Common single-ended impedance is 50Ω, and differential impedance is 100Ω. Impedance mismatch can cause signal reflection, distortion, and radiation, affecting signal integrity. Key parameters for impedance control include:

• Trace Width and Spacing: Primary factors affecting impedance.
• Dielectric Constant: Materials with low dielectric constants help reduce signal delay and loss.
• سمك النحاس: Inner signal layers typically use 0.5oz copper thickness to meet precise etching requirements.

EMC Design

The goal of EMC design is to reduce electromagnetic interference (EMI) and enhance anti-interference capabilities. Some basic principles include:

• Adjacent Power and Ground Layers: Utilize interlayer capacitance as a power smoothing capacitor while shielding radiation currents.
• Routing Layers Adjacent to Power or Ground Layers: Reduce interference through flux cancellation.
• Ground Plane as a Shield Layer: Suppress common-mode RF interference and reduce the distribution impedance of high-frequency power.

Optimization Strategies for High-Speed PCB Stackup Design

Material Selection

High-speed PCBs require materials with low loss tangent (Df) and low dielectric constant (Dk). Common FR-4 materials are suitable for most applications, but for high-speed scenarios, high-performance materials such as Panasonic’s Megtron4/6 series are recommended. على سبيل المثال, Megtron6 exhibits a signal loss of only 0.85dB/inch at 28Gbps, while FR-4 has a loss of up to 2dB/inch.

Fiberglass Effect and Copper Foil Roughness

• Fiberglass Effect: The weaving style of different fiberglass cloths affects signal characteristics. To mitigate the fiberglass effect, choose fiberglass types with minimized resin windows or use Zig-Zag routing methods.
• Copper Foil Roughness: In high-speed signal design, copper foil surface roughness affects signal transmission. Its impact is minimal below 5GHz but becomes significant above 10GHz.

Thermal Management

High-speed PCBs often come with high power consumption, making thermal management crucial. Some optimization strategies include:

• Selecting High Thermal Conductivity Materials: Such as metal-based substrates (aluminum or copper).
• Designing Thermal Pads and Vias: Improve heat conduction efficiency.
• Increasing Ground Planes and Copper Pour Areas: Enhance heat dissipation capabilities.

Practical Applications of PCB Stackup Design

16-Layer Board Stackup Design

Taking a 16-layer board as an example, a typical stackup structure is as follows:

1. Top Layer (Signal Layer)
2. Ground Layer
3. Signal Layer
4. Power Layer
5. Signal Layer
6. Ground Layer
7. Signal Layer
8. Core Layer
9. Signal Layer
10. Ground Layer
11. Signal Layer
12. Power Layer
13. Signal Layer
14. Ground Layer
15. Signal Layer
16. Bottom Layer (Signal Layer)

This structure effectively reduces crosstalk and electromagnetic interference by alternately distributing signal and ground layers while meeting the impedance control requirements of high-speed signals.

Via Structure Design

في مركبات ثنائي الفينيل متعدد الكلور HDI, blind vias and buried vias are widely used to optimize routing space. لكن, these via structures increase manufacturing difficulty and cost. لذلك, via structures should be simplified during design, such as prioritizing through-hole vias (PTH).

خاتمة

PCB stackup design is a complex and critical task involving material selection, layer allocation, impedance control, EMC design, and thermal management. Through rational stackup design, circuit performance and reliability can be improved while effectively controlling costs. For high-speed PCB design, selecting low-loss materials, optimizing fiberglass effects and copper foil roughness, and strengthening thermal management are key to ensuring signal integrity and stability.

Whether you are a beginner or a seasoned engineer, mastering the core principles and optimization strategies of PCB stackup design will lay a solid foundation for the successful design of electronic products.
