UGPCB DS-7409 HG (KQ) IC Package substrate material is Low Df, Halogen & phosphorous free. Applications include Flip chip BoC & RF module.
Glass Epoxy Laminates in Industrial Equipment
Glass Epoxy Laminates, which are widely used in industrial equipment, have been further refined and are helping to promote sustainable economic growth in an environmentally-friendly way in accordance with ongoing changes in our lifestyle. They are the basis on which numerous environmentally-friendly products, including mobile applications, computer systems, and car electronics, have been developed and produced.
DS-7409 Variants
DS-7409
DS-7409S (N)
Material Properties of DS-7409
Tg (Glasübergangstemperatur)
Property: Tg
Einheit: Grad Celsius
Test Condition: DSC
Typical Value: 170
Test Method: IPC-TM-650.2.4.25c
TMA (Thermomechanical Analysis)
Property: TMA
Einheit: Grad Celsius
Test Condition: N/A
Typical Value: 165
Test Method: IPC-TM-650.2.4.24c
CTE Z-axis (Coefficient of Thermal Expansion)
Property: CTE Z-axis
Einheit: ppm/degree Celsius
Test Condition: Ambient to Tg
Typical Value: 41
Test Method: IPC-TM-650.2.4.41
Z-axis Expansion
Property: Z-axis Expansion
Einheit: %
Test Condition: 50 degree Celsius to 260 Grad Celsius
Typical Value: 3.3
Test Method: IPC-TM-650.2.4.41
Decomposition Temperature (5% wt loss)
Property: Decomposition Temperature
Einheit: Grad Celsius
Test Condition: TGA
Typical Value: 295
Test Method: IPC-TM-650.2.4.40
T-260 & T-288 (Thermomechanical Analysis)
Property: T-260
Einheit: min
Test Condition: TMA
Typical Value: 7
Test Method: IPC-TM-650.2.4.24.1
Property: T-288
Einheit: min
Test Condition: TMA
Typical Value: –
Test Method: IPC-TM-650.2.4.24.1
Dielektrizitätskonstante & Dissipationsfaktor
Property: Dielektrizitätskonstante (Harzinhalt 50%)
Einheit: C-24/23/50(1GHz)
Test Condition: N/A
Typical Value: 4.2
Test Method: IPC-TM-650.2.5.5.9
Property: Dissipationsfaktor (Harzinhalt 50%)
Einheit: C-24/23/50(1GHz)
Test Condition: N/A
Typical Value: 0.015
Test Method: IPC-TM-650.2.5.5.9
Peel Strength
Property: Peel Strength (Standard profile 1oz)
Einheit: N/mm
Test Condition: Zustand A
Typical Value: 2.0
Test Method: IPC-TM-650.2.4.8
Water Absorption
Property: Water Absorption
Einheit: %
Test Condition: E-24/50+D-24/23
Typical Value: 0.12
Test Method: IPC-TM-650.2.6.2.1
