Medical Scanner RF PCB Design - そして

RF PCB 設計/

Medical Scanner RF PCB Design

名前: Medical Scanner RF PCB Design

Designable layers: 1-32 レイヤー

Minimum line width and line spacing: 3ミル

Minimum laser aperture: 4ミル

Minimum mechanical aperture: 8ミル

Copper foil thickness: 18-175цm (標準: 18цm35цm70цm)

Peel strength: 1.25N/mm

Minimum punching hole diameter: single side: 0.9mm/35mil

Minimum hole diameter: 0.25mm/10mil

Aperture tolerance: ≤φ0.8mm±0.05mm

Hole tolerance: ±0.05mm

  • 製品詳細

Use in Medical Equipment

RF PCBs have been used in the medical industry for some time. 通常, medical equipment such as X-ray machines and medical scanners are manufactured using RF PCBs.

Use in Medical Implants

The same goes for medical implants such as pacemakers.
