Wifi Bluetooth Module PCB - そして

標準PCBボード/

Wifi Bluetooth Module PCB

モデル : 2L WiFi Bluetooth Module

材料 : FR4

層 : 2レイヤー

色 : Black/White

仕上がり厚さ : 1.0mm

銅の厚さ : 1オズ

表面処理 : イマージョンゴールド

最小トレース : 4ミル(0.1mm)

最小スペース : 4ミル(0.1mm)

characteristic : Half hole PCB

応用 : WiFi Bluetooth Module PCB

  • 製品詳細

材料構成

The 2L WiFi Bluetooth Module is crafted from high-quality FR4, a flame-retardant grade of epoxy glass cloth that offers exceptional electrical, 機械的, and thermal properties. This material ensures durability and reliability in various environmental conditions.

Construction Details

With a sleek design, the module features a 2-layer construction, available in black or white color options. The finished thickness of the PCB is 1.0mm, providing a sturdy base for the electronic components. The copper thickness of 1OZ (ounce) per square foot guarantees efficient heat dissipation and signal transmission.

Surface Finish

To enhance conductivity and corrosion resistance, the surface of the 2L WiFi Bluetooth Module undergoes immersion gold treatment. This process coats the copper traces with a thin layer of gold, ensuring a high-quality electrical connection and long-term stability.

Manufacturing Precision

Precision is key in the production of the 2L WiFi Bluetooth Module. With a minimum trace width and spacing of 4mil (0.1mm), the PCB supports intricate circuit designs while maintaining optimal electrical performance. さらに, the half-hole PCB characteristic allows for versatile component mounting and enhanced circuit integration.

Production Workflow

The production of the 2L WiFi Bluetooth Module involves several meticulous steps:

  1. Design Layout: The initial phase involves creating the PCB layout using specialized software, ensuring all electrical and physical requirements are met.
  2. 材料の準備: High-quality FR4 sheets are cut to size and prepared for the manufacturing process.
  3. Circuit Etching: Using advanced etching techniques, the copper traces are precisely etched onto the FR4 substrate.
  4. 穴あけ加工とメッキ加工: Holes are drilled for component mounting, and the surface is plated with immersion gold to enhance conductivity.
  5. 品質管理: Each PCB undergoes rigorous testing to ensure it meets the required specifications.
  6. Assembly: ついに, the PCB is assembled with the necessary components to form the complete 2L WiFi Bluetooth Module.

アプリケーションシナリオ

The versatility of the 2L WiFi Bluetooth Module makes it ideal for a wide range of applications:

  • Smart Home Devices: Integrate seamlessly into smart home systems, enabling wireless control and monitoring.
  • IoT Products: Perfect for Internet of Things devices that require reliable WiFi and Bluetooth connectivity.
  • Wearable Technology: Enhance the functionality of wearable devices with efficient wireless communication capabilities.
  • Industrial Automation: Facilitate machine-to-machine communication in industrial settings, improving operational efficiency.

In conclusion, the 2L WiFi Bluetooth Module combines superior material quality, precise manufacturing, and versatile application possibilities, making it an excellent choice for developers and engineers seeking reliable wireless connectivity solutions.
