Overview of UGPCB
UGPCB.com has specialized in RF PCB manufacturing for more than 17 years in China. We understand the significant impact of the proper RF material on the board’s performance. Parameters such as RF microwave energy levels, operating frequency, operating temperature range, current, and voltage are crucial when selecting suitable material for high-frequency PCB fabrication.
RF/Microwave PCB Material Expertise
Getting familiar with RF PCB materials is one of our jobs. Check below for a material listing for reference. We have enough of them in stock to ensure fast delivery. Our confidence in product quality stems from our experienced engineers and production team, who cooperate closely with our QA department to provide a qualified product.
RF/Microwave PCB Materials
- Rogers RO4350B / RO3003 / RO4003 / RO3006 / RT/Duroid 5880 / RT5870, etc.
- Arlon / Isola / Taconic / PTFE F4BM / Teflon material should not be forgotten.
Hybrid PCB Material Expertise
We also specialize in Hybrid PCB materials (Mixed dielectric / Laminate):
- Rogers RO4350B + FR4 / RO4350B + IT180 / RO4003C + FR4 / RO3010 + FR4 / RO3003 + FR4 / RO3010 + FR4, etc.
RF Microwave PCB Applications
RF Microwave PCBs (printed circuit board) are used in various fields such as Consumer Electronics, Military/Space, High Power, Medical, Automotive, Industrial, etc.
UGPCB Advantages
Surface Finishing Options
- OSP / ENIG / HASL LF / Plated gold / flash gold / Immersion Tin / Immersion silver / Electrolytic gold
Capacity and Capabilities
- Golden finger / Heavy copper / Blind buried via / impedance control / filled with resin / carbon ink / backdrill / countersink / depth drilling / half plated hole / pressfit hole / peelable blue mask / peelable solderstop / thick copper / oversize
Material Range
- Rogers RO4350B / RO3003 / RO4003 / RO3006 / RT/Duroid 5880 / RT5870 and Arlon / Isola / Taconic / PTFE F4BM / Teflon material, etc.
Layer Counts
- 2L, 4L, 6L, 8L, 10L, 12L, 14L, 16L, 18L, 20L, 22L, 24L, 26L, 28L, 30L
Dielectric Constant (DK)
- 2.20 / 2.55 / 3.00 / 3.38 / 3.48 / 3.50 / 3.6 / 6.15 / 10.2
Applications
- Consumer Electronics / Military/Space / Antenna & Communications System / High Power / Medical / Automotive / Industrial / Handheld device cellular / Wifi Antenna / Telematics and infotainment / Wifi/Computing/Radar/Power Amplifiers
We are grateful to our customers who have accompanied us in developing and improving our capacity and technical field for the past 17 years. Quality is the core value of our company, and we understand its importance for long-term business.
