Definition of Industrial Control PCB

Industrial control product PCB. Circuit boards in electrical equipment that control the normal operation of equipment.

Types of Industrial Control PCBs

Special Circuit Board for Industrial Control

1. Функциональность: A special circuit board designed for a specific industrial control function.
2. Components: The bottom circuit is completed, and IO is reserved.
3. Customization: After purchasing, connect the reserved input and output ports to user equipment like motors, solenoid valves, and sensors to achieve desired functionality.

Dedicated Circuit Boards

1. Цель: Specifically designed for a single function, such as a temperature control circuit board.
2. Connections: The input port connects to a thermocouple, and the output port connects to a heating contactor or solid-state relay.
3. Приложения: Used in control panels, motion control panels, and other specific industrial applications.

Universal Control Board

1. Programmability: Most universal control boards can be programmed.
2. Customization: Through user-driven secondary development, specific functions are completed.
3. Versatility: Used in a wide range of applications.
4. Examples: PLC (Programmable Logic Controller) is a common universal industrial control board.
5. Функции:
   • User-written programs and compiled inputs.
   • Digital input, analog input port, high-speed counter port, digital output port, analog output port.
   • Some PLCs also have communication functions.
